Single-Axle Farm Trailer
Single-Axle Farm Trailer
Single-Axle Farm Trailer
Specification
型号 Model | 单位unit | 7C-1.5/7CX-1.5 | 7C-2/7CX-2 | 7C-3/7CX-3 | 7C-4/7CX-4 |
额定载重 Loading weight | kg | 1500 | 2000 | 3000 | 4000 |
车厢尺寸 Box size | mm | 2000*1000*450 | 2200*1200*450 | 2500*1400*450 | 2800*1500*450 |
轮胎型号/数量 Tyre /Q’ty | 6.50-16/2 | 6.50-16/2 | 7.50-16/2 | 7.50-16/2 | |
整机重量 Total weight | kg | 280/340 | 300/370 | 650/740 | 750/860 |
制动形式 Brake | 机械或充气制动mechanical or air pneumatic brake | ||||
配套动力 Matched power | hp | 15-25 | 20-30 | 30-40 | 40-50 |
挂接方式 Linkage | 牵引Trailed | ||||
选装配置 The items selectable | 单作用油缸自卸,油管接头1/2”锥螺纹,气体接头M20*1.5 Tipping single action oil cylinder,oil connection in 1/2” thread,gas connection | ||||
